| WIRELESS | |
| Standards | Wi-Fi 5
IEEE 802.11ac/n/a 5 GHz
IEEE 802.11n/b/g 2.4 GHz |
| WiFi Speeds | AC750
5 GHz: 433 Mbps (802.11ac)
2.4 GHz: 300 Mbps (802.11n) |
| WiFi Range | 2 Bedroom Houses
2× Fixed Antennas (Internal) |
| WiFi Capacity | Medium
Dual-Band
Allocate devices to different bands for optimal performance |
| Working Modes | Router Mode
Access Point Mode
Range Extender Mode
Client Mode
Hotspot Mode (WISP Mode) |
| HARDWARE | |
| Processor | Single-Core CPU |
| Ethernet Ports | 1× 10/100 Mbps WAN/LAN Port |
| USB Support | 1× USB 2.0 Port
Supported Partition Formats:
NTFS, FAT32
Supported Functions:
FTP Server
Media Server |
| Buttons | Reset Button
Mode Switch |
| Power | 5 V ? 2 A |
| SECURITY | |
| WiFi Encryption | WEP
WPA
WPA2 |
| Network Security | SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway |
| Guest Network | 1× 5 GHz Guest Network
1× 2.4 GHz Guest Network |
| SOFTWARE | |
| Protocols | IPv4
IPv6 |
| Parental Controls | URL Filtering
Time Controls |
| WAN Types | Dynamic IP
Static IP
PPPoE
PPTP
L2TP |
| Quality of Service | QoS by Device |
| NAT Forwarding | Virtual Server
Port Forwarding
Port Triggering
DMZ
UPnP |
| IPTV | IGMP Proxy |
| DHCP | Address Reservation
DHCP Client List
Server |
| DDNS | NO-IP
Comex
DynDNS |
| Management | Tether App
Webpage
|
| PHYSICAL | |
| Dimensions (W×D×H) | 2.91 × 2.64 × 0.87 in
(74 × 67 × 22mm) |
| Weight | 56.7 g |
| Package Contents | Wi-Fi Router TL-WR902AC
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide |
| OTHER | |
| System Requirements | Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access) |
| Certifications | FCC, CE, RoHS |
| Environment | Operating Temperature: 0°C~40°C (32°F ~104°F)
Storage Temperature: -40°C~70°C (-40°F ~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
| TEST DATA | |
| WiFi Transmission Power | CE:
<20dBm(2.4GHz)
<23dBm(5GHz) |
| WiFi Reception Sensitivity | 11a 54M: -76dBm; 11ac VHT20 MCS8: -70dBm;
11ac VHT40 MCS9: -65.5dBm; 11ac VHT80 MCS9:
-61.5dBm
2.4GHz:
11g 54M: -76dBm11n; HT20 MCS7: -74dBm;
11n HT40 MCS7: -71dBm |
