| 4G |
| Network Type | 4G
FDD-LTE: B1/B3/B5/B7/B8/B20/B28
(2100/1800/850/2600/900/800/700 MHz)
TDD-LTE: B38/B40/B41
(2600/2300/2500 MHz)
|
3G:
DC-HSPA+/HSPA/UMTS:B1/B5/B8(2100/850/900 MHz)
| Speed | Download Speed 150 Mbps
Upload Speed 50 Mbps |
| SIM Type | 1×Nano SIM Card |
| HARDWARE |
| Interface | 1× 100 Mbps WAN/LAN Port (PoE In)
1× Nano SIM Card Slot
1 × DC Port |
| Buttons | 1× Reset Button |
| Power | 12V/1A DC
48V/0.375A Passive PoE
44-57V/0.35A 802.3af |
| Dimensions (W x D x H) | 8.9 x 3.9 x 2.2 in (226.6 x 100x 54.7mm) |
| Antennas | 2 × Detachable LTE Antennas |
| WIRELESS FEATURES |
| Wireless Standards | IEEE 802.11b/g/n |
| Frequency | 2.4 GHz |
| Signal Rate | 300 Mbps |
| Reception Sensitivity | 11g 54M: -74 dBm
11n HT20: -73 dBm
11n HT40: -70 dBm |
| Wireless Functions | Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics |
| Wireless Security | WPA/WPA2, WPA-PSK/WPA2-PSK encryptions |
| SOFTWARE FEATURES |
| Security | DoS, IPv4 SPI Firewall, IP and MAC Address Binding |
| Operating Modes | 3G/4G Router, Wireless Router |
| WAN Type | Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access) |
| Management Features | Local Management, Remote Management |
| DHCP | Server, DHCP Client List, Address Reservation |
| Port Forwarding | ALG, Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS | TP-Link, DynDns, NO-IP |
| Protocols | IPv4, IPv6 |
| Guest Network | 2.4 GHz guest network |
| Administration | Upgrade Firmware, Factory Default, System Log, Diagnostic Tools |
| OTHERS |
| Package Content | 1× TL-MR100-Outdoor Unit
1× 10-meter RJ45 Ethernet Cable
1× PoE Adapter
1× AC Power Cord
1× Quick Installation Guide
Window/Pole/Wall Mounting Kits |
| Requirements | Edge, Firefox, Chrome, Safari, or other JavaScript-enabled browser
*You are recommended to use the latest version |
| Certifications | CE, RoHS |
| Environment | Operating Temperature: -30°C~60°C (-22°F~140°F)
Storage Temperature: -40°C~70°C (-40 °F~158 °F)
Operating Humidity: 10%~90% RH
Storage Humidity: 5%~90% RH |
