| CAMERA |
| Image Sensor | 1/2.7” Progressive Scan CMOS Starlight Sensor |
| Lens | Focal Length: 4.0mm
Aperture: F1.6
Field of View: 105° (Diagonal), 88°(Horizontal), 46°(Vertical) |
| Night Vision | 1× 850 nm IR LEDs (40 ft / 20 m)
Full-Color Night Vision1 |
| Day/Night Mechanism | IR-Cut Filter with Auto-Switching |
| Max. Resolution | 2880 × 1620 px |
| Interface & Button | 1× RESET Button
1× microSD Card Slot (Up to 512 GB) |
| Video and Audio |
| Live View | Yes |
| Frame Rate | 30 fps |
| Video Compression | H.264 |
| Audio Input & Output | Built-in Microphone and Speaker |
| Audio Communication | Two-Way Audio with Noise Cancellation |
| STORAGE |
| Local Storage | microSD Card Slot on Camera (Up to 512 GB) |
| Cloud Storage | Tapo Care Cloud Storage Services (Subscription required) |
| DETECTION and NOTIFICATIONS |
| AI Detection | Motion Detection
Person Detection
Pet Detection
Vehicle Detection
Line-Crossing Detection
Baby Cry Detection
Tamper Detection |
| Activity Zones | Yes
*Only works with Motion Detection and Person Detection. |
| Output Notification | System Notification
System Notification with Snapshot (Tapo Care Services) |
| NETWORK |
| Network Connectivity | Connect via Wi-Fi |
| Wireless Connectivity | IEEE 802.11b/g/n, 2.4 GHz Wi-Fi |
| Protocol | TCP/IP, DHCP, ICMP, DNS, NTP, HTTPS, TCP, UDP |
| RTSP | Yes |
| ONVIF | Yes |
| Transmission Rate | 11b: 11 Mbps
11g: 54 Mbps
11n: 72.2 Mbps |
| SECURITY |
| Security | On-Device Machine Learning
128-bit AES Encryption with SSL/TLS
WPA/WPA2-PSK |
| POWER |
| Power Source | 5 V DC Power Adapter |
| Input Voltage | 100-240 V, 50/60 Hz |
| Output Voltage | 5.0 V, 1.0 A (Type-C Power) |
| DC Power Connector Size | Adapter: USB A
Camera: USB Type C |
| Power Cord Length | 2 m |
| Typical Power Consumption | 2.3 W |
| Maximum Power Consumption | 5 W |
| GENERAL |
| Smart Integration | Google Assistant, Amazon Alexa, Samsung SmartThings |
| Weather Resistance | IP65 |
| Mounting Options | Tabletop
Wall-Mounted
Ceiling-Mounted
Pole-Mounted |
| Operating Temperature | -20 oC ~ 50 oC (-4 °F ~ 122 °F) |
| Storage Temperature | -40 oC ~ 60 oC (-40 °F ~ 140 °F) |
| Operating Humidity | 10% ~ 90% RH, Non-condensing |
| Storage Humidity | 0 ~ 90% RH, Non-condensing |
| Dimensions ( W x D x H ) | 4.15 × 3.06 × 2.75 in (105.3 × 77.8 × 69.8 mm) |
| Weight | 7.76 oz / 220 g |
| Package Content | Tapo C236 Camera × 1
Mounting Bracket × 1
Mounting Template × 1
Mounting Anchors × 4
Mounting Screws × 4
Power Adapter × 1
2 m USB Adapter Cable × 1
Quick Start Guide × 1 |
