| WIRELESS |
|
| Working Modes |
Range Extender/Access Point |
| HARDWARE FEATURES |
|
| Ports |
1 Gigabit Ethernet Port |
| Button |
WPS Button, Reset Button |
| Input Power |
100-240V~50/60Hz |
| Power Consumption |
10W |
| Dimensions ( W x D x H ) |
3.1×1.4×5.9 in. (78×36×149 mm) |
| Antenna |
2 Internal Antennas |
| WIRELESS FEATURES |
|
| Wireless Standards |
IEEE 802.11a/n/ac/ax 5GHz, IEEE 802.11b/g/n 2.4GHz |
| Frequency |
2.4GHz and 5GHz |
| Signal Rate |
300 Mbps at 2.4GHz, 1200 Mbps at 5GHz |
| Reception Sensitivity |
5GHz: 11a 6Mbps: -93dBm, 11a 54Mbps: -75dBm 11ac HT20 MCS0: -92dBm, 11ac HT20 MCS8: -70dBm 11ac HT40 MCS0: -90dBm, 11ac HT40 MCS9: -66dBm 11ac HT80 MCS0: -87dBm, 11ac HT80 MCS9: -62dBm 2.4GHz: 11g 54Mbps: -77dBm, 11n HT20 MCS7: -75dBm 11n HT40 MCS7: -72dBm |
| Transmit Power |
CE: 2.4GHz <20dBm, 5GHz <30dBm |
| Wireless Functions |
Enable/Disable Wireless Radio, Wireless Statistics |
| Wireless Security |
64/128-bit WEP, WPA/WPA-PSK2 encryptions |
| Transmission Power |
CE: 2.4GHz <20dBm, 5GHz <30dBm |
| OTHERS |
|
| Certification |
FCC, RoHS |
| Package Contents |
Wi-Fi Range Extender RE500X Quick Installation Guide |
| System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser |
| Certifications |
FCC, RoHS |
| Environment |
Operating Temperature: 0°C~40°C (32°F ~104°F) Storage Temperature: -40°C~70°C (-40°F ~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
