| WIRELESS |
|
| Standards |
Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/b/g 2.4 GHz |
| WiFi Speeds |
AX3000
5 GHz: 2402 Mbps (802.11ax, HE160)
2.4 GHz: 574 Mbps (802.11ax) |
| WiFi Range |
TP-Link Mesh Technology
Optional Ethernet backhaul work together to link Deco units to provide seamless coverage
AI-Driven Mesh
Intelligently learns the network environment to provide ideal Wi-Fi unique to your home
2× Antennas (Internal)
Multiple antennas form a signal-boosting array to cover more directions and large areas |
| WiFi Capacity |
High
Dual-Band
Distribute devices to different bands for optimal performance
2×2 MU-MIMO
Simultaneously communicates with multiple MU-MIMO clients
OFDMA
Simultaneously communicates with multiple WiFi 6 clients
4 Streams
More than enough bandwidth for connected devices |
| Working Modes |
Router Mode
Access Point Mode |
| HARDWARE FEATURES |
|
| Power Supply |
• 802.3at PoE
• 12V DC
(EU Version: 12V/1.2A DC. US Version: 12V/1.5A DC).
Note: DC adapter is included in the package |
| HARDWARE |
|
| Button |
Reset Button |
| Ethernet Ports |
1× 2.5 Gbps port + 1× Gigabit port
*Per Deco Unit
Supports WAN/LAN auto-sensing |
| SECURITY |
|
| WiFi Encryption |
WPA-Personal
WPA2-Personal
WPA3-Personal |
| Network Security |
SPI Firewall
Access Control
HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner |
| Guest Network |
1× 5 GHz Guest Network
1× 2.4 GHz Guest Network |
| SOFTWARE |
|
| Protocols |
IPv4
IPv6 |
| Service Kits |
HomeShield
Learn More> |
| Parental Controls |
HomeShield Parental Controls
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports |
| WAN Types |
Dynamic IP
Static IP
PPPoE
PPTP
L2TP |
| Quality of Service |
HomeShield QoS
QoS by Device |
| Cloud Service |
OTA Firmware Upgrade
TP-Link ID
DDNS |
| NAT Forwarding |
Port Forwarding
UPnP |
| IPTV |
IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN |
| DHCP |
Address Reservation
DHCP Client List
Server |
| DDNS |
TP-Link |
| Management |
Deco App |
| TEST DATA |
|
| WiFi Transmission Power |
CE: FCC: |
| PHYSICAL |
|
| Dimensions (W×D×H) |
6.1 × 6.1 × 2.7 in
(154× 154 × 68.6 mm) |
| Package Contents |
1× Deco X50-PoE units
1× RJ45 Ethernet cable
1× Power adapters
Ceiling/Wall Mounting Kits
Quick Installation Guide |
| OTHERS |
|
| System Requirements |
Android 5.0 or later
iOS 9.0 or later
*Note: The minimum system requirements will be updated alongside updates to the app, subject to official website information. |
| Certifications |
CE, FCC, RoHS |
| Environment |
Operating Temperature: 0°C~40°C (32 °F~104 °F)
Storage Temperature: -40°C~60°C (-40 °F~140 °F)
Operating Humidity: 10%~90% RH
Storage Humidity: 5%~90% RH |
