| HARDWARE FEATURES |
|
| VDSL2 Standards |
ITU G.993.2, Up to 35b profile (POTS)
ITU-T G.993.5 (G.vector)
ITU-T G.998.4 (G.INP) |
| ADSL Standards |
Full-rate ANSI T1.413 Issue 2
ITU-T G.992.1(G.DMT)
ITU-T G.992.2(G.Lite) |
| ADSL2 Standards |
ITU-T G.992.3 (G.DMT.bis) |
| ADSL2+ Standards |
ITU-T G.992.5 |
| WIRELESS |
|
| Standards |
Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/b/g 2.4 GHz |
| WiFi Speeds |
AX3000
5 GHz: 2402 Mbps (802.11ax)
2.4 GHz: 574 Mbps (802.11ax) |
| WiFi Range |
1-3 Bedroom Houses (1-pack)
TP-Link Mesh Technology
Optional Ethernet backhaul work together to link Deco units to provide seamless coverage
2× Antennas (Internal)
Multiple antennas form a signal-boosting array to cover more directions and large areas |
| WiFi Capacity |
High
Dual-Band
Distribute devices to different bands for optimal performance
MU-MIMO
Simultaneously communicates with multiple MU-MIMO clients
OFDMA
Simultaneously communicates with multiple WiFi 6 clients
4 Streams
More than enough bandwidth for connected devices |
| Working Modes |
DSL (only on Deco X50-DSL)
Router
Access Point |
| HARDWARE |
|
| Ethernet Ports |
4× Gigabit Ports Per Deco X50-DSL Unit
Supports WAN/LAN auto-sensing |
| Buttons |
RESET Button |
| Ports and Connections |
1 DSL Port
Compatibility
VDSL2 / ADSL2+ / ADSL2 / ADSL |
| SECURITY |
|
| WiFi Encryption |
WPA-Personal
WPA2-Personal
WPA3-Personal |
| Network Security |
SPI Firewall
Access Control
HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner |
| Guest Network |
1× 5 GHz Guest Network
1× 2.4 GHz Guest Network |
| SOFTWARE |
|
| Protocols |
IPv4
IPv6 |
| Service Kits |
HomeShield
Learn More> |
| WAN Types |
Dynamic IP
Static IP
PPPoE
L2TP
PPTP
PPPoA
IPoA
DS-Lite |
| Quality of Service |
HomeShield QoS
QoS by Device |
| Cloud Service |
OTA Firmware Upgrade
TP-Link ID
DDNS |
| NAT Forwarding |
Port Forwarding
UPnP |
| IPTV |
IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN |
| DHCP |
Address Reservation
DHCP Client List
Server |
| DDNS |
TP-Link |
| Management |
Deco App |
| TEST DATA |
|
| WiFi Transmission Power |
CE:
<20 dBm (2.4GHz)
<23 dBm (5GHz) |
| PHYSICAL |
|
| Dimensions (W×D×H) |
Deco X50-DSL:
4.13 × 4.13 × 6.57 in
(105 × 105 × 167mm) |
| Package Contents |
1-pack
1 Deco X50-DSL Unit
1 RJ45 Ethernet Cable
2 RJ11 DSL Cables
1 External DSL Splitter
1 Power Adapter
Quick Installation Guide |
| OTHERS |
|
| Certification |
Deco X50-DSL:
CE, RCM, RoHS |
| Environment |
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~60°C (-40°F~140°F)
Operating Humidity: 10%~90%RH
Storage Humidity: 5%~90%RH |
