| WIRELESS |
| Standards | Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11n/b/g 2.4 GHz |
| WiFi Speeds | AX1500
5 GHz: 1201Mbps (802.11ax)
2.4 GHz: 300 Mbps (802.11n) |
| WiFi Range | 1-2 Bedroom Houses (1-pack)
TP-Link Mesh Technology
Optional Ethernet backhaul work together to link Deco units to provide seamless coverage
2 LTE antennas, 2 Wi-Fi antennas (Internal)
Multiple antennas form a signal-boosting array to cover more directions and large areas |
| WiFi Capacity | High
Dual-Band
Distribute devices to different bands for optimal performance
2×2 MU-MIMO
Simultaneously communicates with multiple MU-MIMO clients
OFDMA
Simultaneously communicates with multiple WiFi 6 clients
4 Streams
More than enough bandwidth for connected devices |
| Working Modes | 3G/4G, Router, Access Point |
| SECURITY |
| Network Security | SPI Firewall
Access Control |
| Guest Network | 1× 5 GHz Guest Network
1× 2.4 GHz Guest Network |
| WiFi Encryption | WPA-Personal
WPA2-Personal
WPA3-Personal |
| HARDWARE |
| Ethernet Ports | 3× Gigabit Ports
Supports WAN/LAN auto-sensing |
| Buttons | RESET Button |
| Ports and Connections | 2× 3G/4G external SMB antenna interface (also provide 2x SMB to SMA-F Adapters)
SIM Card Format: Nano-SIM
Compatibility
4G:
FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
TDD-LTE: B38/B40/B41 (2600/2300/2500 MHz)
3G: DC-HSPA+/HSPA/UMTS B1/B5/B8 (2100/850/900 MHz) |
| SOFTWARE |
| Protocols | IPv4
IPv6 |
| Parental Controls | Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Report |
| WAN Types | Dynamic IP
Static IP
PPPoE
L2TP
PPTP |
| Quality of Service | QoS by Device |
| Cloud Service | OTA Firmware Upgrade
TP-Link ID
DDNS |
| NAT Forwarding | Port Forwarding
UPnP |
| IPTV | IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN |
| DHCP | Address Reservation
DHCP Client List
Server |
| DDNS | TP-Link |
| Management | Deco App |
| TEST DATA |
| WiFi Transmission Power | CE:
?20 dBm (2.4GHz)
?23 dBm (5GHz) |
| PHYSICAL |
| Dimensions (W×D×H) | 4.13 × 4.13 × 6.57 in (105 × 105 × 167 mm) |
| OTHERS |
| Certification | CE, RoHS |
| Package Contents | 1-pack
1 Deco X10-4G unit
1 RJ45 Ethernet Cable
1 Power Adapter
2 SMB to SMA Adapters
Quick Installation Guide |
| Environment | Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~60°C (-40°F~140°F)
Operating Humidity: 10%~90%RH
Storage Humidity: 5%~90%RH |
