| General Feature |
|---|
| Application | Client PCs, Game Consoles |
|---|
| Capacity | 2,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise) |
|---|
| Form Factor | M.2 (2280) |
|---|
| Interface | PCIe Gen 4.0 x4, NVMe 2.0 |
|---|
| Dimension (WxHxD) | 80 x 24.3 x 8.2 mm (with heatsink) |
|---|
| Weight | Max 28.0g Weight |
|---|
| Storage Memory | Samsung V-NAND 3-bit MLC |
|---|
| Controller | Samsung in-house Controller |
|---|
| Cache Memory | Samsung 2GB Low Power DDR4 SDRAM |
|---|
| Special Feature |
|---|
| TRIM Support | Supported |
|---|
| S.M.A.R.T Support | Supported |
|---|
| GC (Garbage Collection) | Auto Garbage Collection Algorithm |
|---|
| Encryption Support | AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive) |
|---|
| WWN Support | Not supported |
|---|
| Device Sleep Mode Support | Yes |
|---|
| Performance |
|---|
| Sequential Read | Up to 7,450 MB/s * Performance may vary based on system hardware & configuration |
|---|
| Sequential Write | Up to 6,900 MB/s * Performance may vary based on system hardware & configuration |
|---|
| Random Read (4KB, QD32) | Up to 1,400,000 IOPS * Performance may vary based on system hardware & configuration |
|---|
| Random Write (4KB, QD32) | Up to 1,550,000 IOPS * Performance may vary based on system hardware & configuration |
|---|
| Random Read (4KB, QD1) | Up to 22,000 IOPS * Performance may vary based on system hardware & configuration |
|---|
| Random Write (4KB, QD1) | Up to 80,000 IOPS * Performance may vary based on system hardware & configuration |
|---|
| Environment |
|---|
| Average Power Consumption (system level) | *Average: 5.5 W*Maximum: 8.5 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration |
|---|
| Power consumption (Idle) | Max. 55 mW * Actual power consumption may vary depending on system hardware & configuration |
|---|
| Allowable Voltage | 3.3 V ± 5 % Allowable voltage |
|---|
| Reliability (MTBF) | 1.5 Million Hours Reliability (MTBF) |
|---|
| Operating Temperature | 0 - 70 °C Operating Temperature |
|---|
| Shock | 1,500 G & 0.5 ms (Half sine) |
|---|
| Accessories |
|---|
| Installation Kit | Not Available |
|---|
| Software |
|---|
| Management SW | Magician Software for SSD management |
|---|
| Warranty |
|---|
| Warranty | 5-Year Limited Warrantyor 1200 TBW Limited Warranty |
|---|
