| Scanner Type |
ADF (Automatic Document Feeder) / Manual Feed, Duplex |
Scanning Speed*1 (A4 Portrait)
(Color*2/Grayscale*2/Monochrome*3) |
Simplex |
70 ppm (200/300 dpi) |
| Duplex |
140 ipm (200/300 dpi) |
| Image Sensor Type |
CIS x 2 (front x 1, back x 1) |
| Light Source |
RGB LED x 2 (front x 1, back x 1) |
| Optical Resolution |
600 dpi |
Output Resolution*4
(Color / Grayscale / Monochrome) |
50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver)*5 |
| Output Format |
Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit |
| Background Colors |
White / Black (selectable) |
| Document Size |
Maximum*6 |
215.9 x 355.6 mm (8.5 x 14 in.) |
| Minimum |
48 x 50 mm (1.9 x 2 in.) |
| Long Page Scanning*7 |
6,096 mm (240 in.) |
| Paper Weight (Thickness) |
Paper |
20 to 465 g/m2 (5.3 to 124 lb)*8 |
| Booklet |
Less than 7 mm (0.276 in.)*9 |
| Plastic Card |
1.4 mm (0.055 in.) or less*10 |
| ADF Capacity*11*12 |
100 sheets (A4 80 g/m2 or Letter 20 lb) |
| Expected Daily Volume*13 |
10,000 sheets |
| Multifeed Detection |
Overlap detection (Ultrasonic sensor), Length detection |
| Paper Protection |
Image monitoring, Sound detection (iSOP)*14 |
| Interface |
USB |
USB 3.2 Gen1x1 / USB 2.0 / USB 1.1 |
| Ethernet |
10BASE-T, 100BASE-TX, 1000BASE-T |
| Power Requirements |
AC 100V - 240V 50/60 Hz |
| Power Consumption |
Operating Mode |
28 W or less / 17 W (Eco mode) |
| Sleep Mode |
LAN: 2.0 W or less
USB: 1.4 W or less |
| Auto Standby (Off) Mode |
0.2 W or less |
| Operating Environment |
Temperature |
5 to 35 °C (41 to 95 °F) |
| Relative Humidity |
15 to 80% (Non-condensing) |
| Environmental Compliance |
ENERGY STAR, RoHS |
| Dimensions (W x D x H)*15 |
300 x 170 x 163 mm (11.8 x 6.7 x 6.4 in.) |
| Weight |
4 kg (8.8 lb) |
| Supported Operating System |
Windows 11*16, Windows 10*16, Windows 8.1, Windows 7, Windows Server 2022, Windows Server 2019, Windows Server 2016, Windows Server 2012 R2, Windows Server 2012, Windows Server 2008 R2, macOS, Linux (Ubuntu) |
| Included Software / Drivers |
PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), WIA Driver*17, Image Scanner Driver for macOS (ICA)*17*18, Image Scanner Driver for Linux (SANE)*17*18, PaperStream Capture, PaperStream ClickScan*18, Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap™*18, Scanner Central Admin |
| Image Processing Functions |
Multi image output, Automatic color detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom), sRGB output, Hole punch removal, Index tab cropping, Split image, De-Skew, Edge filler, Vertical streaks reduction, Background pattern removal, Cropping, Static threshold |
| Included Items |
ADF paper chute, AC cable, AC adapter, USB cable, Setup DVD-ROM |
