| Wireless |
|
| Network Type |
Support 4G/3G network
FDD-LTE: B1/B3/B5/B7/B8/B20/B28(2100/1800/850/2600/900/800/700 MHz)
TDD-LTE: B38/B40 (2600/2300 ?Hz)
HSPA+/UMTS: B1/B5/B8 (2100/850/900 ?Hz)
|
| Wireless Standards |
IEEE 802.11ax/b/g/n 2.4 GHz
|
| Frequency |
2.4 GHz |
| Reception Sensitivity |
11b 11Mbps: -87.5dBm
11g 54Mbps: -74dBm
11n HT20 MCS7: -71dBm
11n HT40 MCS7: -69dBm |
| Transmission Power |
<20dBm |
| Wireless Security |
Support WPA-PSK/WPA2-PSK,Wireless MAC Filtering, Enable/Disable SSID Broadcast |
| Software |
|
| Server, Client, DHCP Client List |
| Hardware |
|
| Dimensions (W X D X H) |
111.1 × 71.6 × 24.2 mm (4.37 × 2.82 × 0.95 in) |
| Interfaces |
1 USB-C port for power supply
1 Nano SIM card slot
|
| Button |
Power Button, Reset Button, Menu Button |
| External Power Supply |
5V/1A |
| External Power Supply |
5V/1A |
| Antenna Type |
Internal Antennas |
| Data Rates |
4G LTE Speed: DL: 150 Mbps, UL: 50 Mbps
WiFi Speed: 287 Mbps on 2.4 GHz |
| Screen Display |
1.44 inch TFT |
| Others |
|
| Network Services Enabled by Default |
Web Server
Manage and configure device through web
• Port: 80/443 Protocol: HTTP/HTTPS
DHCP/DHCPv6
IP address assignment
• Port: 67/547 Protocol: UDP
DNS
DNS
• Port: 53 Protocol: UDP
Dropbear
Manage and configure device through app
• Port: 20001 Protocol: SSH
App management
Manage and configure device through app
• Port: 20002 Protocol: TMP
|
| Package Contents |
Mobile Wi-Fi MT115
USB-C Cable
Quick Installation Guide
|
| Environment |
Operating Temperature: 0°C~35°C (32°F~95°F)
Storage Temperature: -10°C~40°C (14°F~104°F)
Operating Humidity: 0%~75% Non-Condensing
Storage Humidity: 0%~65% Non-Condensing
|
| System Requirements |
Windows 11/10/8/7, Mac OS, Android, iOS, Windows Phone
|
