| Wireless |
|
| Wireless Standards |
IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n/ac 2.4 GHz |
| Frequency |
2.4 GHz, 5 GHz |
| Signal Rate |
867 Mbps (5 GHz) + 300 Mbps (2.4 GHz), compatible with 11ac/a/b/g/n Wi-Fi standards |
| Reception Sensitivity |
11g 6Mbps: -96dBm 11g 54Mbps: -78dBm 11n HT40 MCS7: -74dBm 11n HT20 MCS7: -71dBm 11a 6Mbps: -97dBm 11a 54Mbps: -79dBm 11ac VHT20 MCS8: -74dBm 11ac VHT40 MCS9: -70dBm 11ac VHT80 MCS9: -65dBm |
| Transmission Power |
2.4 GHz < 20dBm (EIRP) 5 GHz < 23dBm (EIRP) |
| Wireless Security |
WPA-PSK / WPA2-PSK |
| Hardware |
|
| Dimensions (W X D X H) |
6.3 × 5.0 × 1.5 in (159.7 × 125.9 × 37.1 mm) |
| Interfaces |
1× Gigabit WAN Port + 2× Gigabit LAN Ports |
| Button |
WPS/Reset Button |
| Antenna Type |
4× 5 dBi Fixed Omni-Directional Antennas |
| Software |
|
| WAN Type |
Dynamic IP/Static IP/PPPoE/L2TP/PPTP |
| Management |
Access Control Local Management Remote Management |
| DHCP |
Server, DHCP Client List |
| NAT Forwarding |
Port Forwarding, Port Triggering, UPnP, DMZ |
| Firewall Security |
SPI Firewall, IP and MAC Address Binding |
| Operation Modes |
Router Mode, Access Point Mode |
| Guest Network |
2.4 GHz Guest Network, 5 GHz Guest Network |
| Others |
|
| Package Contents |
• AC1200 Wireless Dual Band Gigabit Router (MR30G) • Power Adapter • Quick Installation Guide • RJ45 Ethernet Cable |
| Environment |
• Operating Temperature: 0°C~40°C (32°F~104°F) • Operating Humidity: 10%~90% Non-Condensing • Storage Humidity: 5%~90% Non-Condensing |
