| CAMERA |
| Image Sensor | 1/2.7'' Progressive Scan CMOS Not Starlight Sensor |
| Lens | Focal Length: 4 mm
Aperture: F2.0
Field of View: 103° (Diagonal), 86°(Horizontal), 46°(Vertical) |
| Motion Range | Pan Mechanical Range: 340° (360° Pan Coverage)
Tilt Mechanical Range: 70° (110° Tilt Coverage) |
| Night Vision | 850 nm IR LED (40 ft / 12 m ) |
| Interface & Button | 1× RESET Button
1× MicroSD Card Slot (Up to 512 GB) |
| VIDEO & AUDIO |
| Maximum Resolution | 3K 5MP (2880×1620 px) |
| Digital Zoom | Supports 13.5x zoom |
| Frame Rate | 15/20/25/30 fps (Default 20 fps) |
| Video Compression | H.264 |
| Live View | Yes |
| Image Enhancement | 3DNRBLC |
| Audio Input & Output | Built-in Microphone and Speaker |
| Audio Communication | 2-way audio |
| Siren Volume | 90dB (Level measured at 4-inch/10-cm distance) |
| Software |
| Security | On-Device Machine Learning
128 bit AES encryption with SSL/TLS
WPA/WPA2-PSK |
| STORAGE |
| Local Storage | MicroSD Card Slot on Camera (Up to 512 GB) |
| Cloud Storage | MERCUSYS Camera Care Cloud Storage Services (Subscription required) |
| NETWORK |
| Network Connectivity | Connect via Wi-Fi |
| Wireless Connectivity | 11Mbps(802.11b)
54Mbps(802.11g)
72.2Mbps(802.11n) |
| Max. Distance Between Hub and Camera/Doorbell | / |
| RTSP | Yes |
| ONVIF | Yes |
| Power |
| Power Source | 9V DC Power Adapter |
| Input Voltage | 100-240VAC, 50/60Hz, 0.3A |
| Output Voltage | 9.0V/0.6A |
| DETECTION and NOTIFICATIONS |
| Sensor | / |
| AI Detection | Motion detection
Person Detection
Baby Crying Detection
Vehicle Detection
Pet Detection
Meow Detection
Bark Detection
Glass-Breaking Detection |
| Activity Zones | Yes |
| Output Notification | System Notification |
| GENERAL |
| Smart Integration | Google Assistant, Amazon Alexa, Samsung SmartThings |
| Weather Resistance | / |
| Mounting Options | Tabletop
Ceiling-Mounted |
| Operating Temperature | 0 oC ~ 40 oC (32°F ~ 104°F |
| Storage Temperature | -40°C~60°C (-40°F~140°F) |
| Operating Humidity | 10%~90%RH, Non-condensing |
| Storage Humidity | 0%~90%RH, Non-condensing |
| Charging Temperature | / |
| Dimensions ( W x D x H ) | 78.4 × 78.4 × 105.6 mm (3.09 × 3.09 × 4.16 in) |
| Others |
| Certifications | CE, NCC, BSMI, NTRA, KC, RCM, ONVIF |
| Package Content | Pan/Tilt Home Security Wi-Fi Camera (MC230) × 1
Power Adapter × 1
Mounting Anchors × 2
Mounting Screws × 2
Mounting Template Sticker × 1
Quick Start Guide |
