| Wireless |
| Network Type | FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz) |
| | TDD-LTE: B38/B40 (2600/2300 MHz) |
| | HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz) |
| Wi-Fi Class | N300 |
| Wi-Fi (2.4 GHz) | 300 Mbps |
| Wireless Standards | IEEE 802.11b/g/n |
| Frequency | 2.4 GHz |
| Reception Sensitivity | 11g 54M:-74.5dBm |
| | 11n HT20 MCS7:-74.5dBm |
| | 11n HT40 MCS7:-71.5dBm |
| Transmission Power | < 20 dBm (2.4 GHz) |
| Wireless Security | WPA-PSK / WPA2-PSK |
| Wireless Functions | smart connect |
| | WPS |
| | Wireless Schedule |
| | Wireless Clients Statistics |
| Software |
| Operation Modes | 3G/4G Router |
| | Wireless Router |
| Cellular Mode | 4G Preferred |
| | 4G Only |
| | 3G Only |
| Cellular Mode | 4G Preferred |
| | 4G Only |
| | 3G Only |
| Cellular APN | Data Roaming |
| | Network Search |
| | Profile Create |
| | APN Settings |
| | ISP File Upgrade |
| | PIN Management |
| WAN Mode | Dynamic IP |
| | Static IP |
| | PPPoE |
| | PPTP |
| | L2TP |
| DHCP | Server |
| | DHCP Client List |
| | Address Reservation |
| NAT Forwarding | ALG |
| | Virtual Server |
| | Port Triggering |
| | UPnP |
| | DMZ |
| Protocols | IPv4, IPv6 |
| Data Settings | Data Statistics |
| | Data Limit |
| Guest Network | 2.4 GHz Guest Network |
| Parental Controls | Time Control |
| | Website Filtering |
| DDNS | MERCUSYS DDNS |
| | DynDns |
| | NO-IP |
| SMS | Inbox |
| | New Message |
| | Outbox |
| | Drafts |
| Security | IPv4 SPI Firewall |
| | Access Control |
| | Service Filtering |
| | IP & MAC Binding |
| | IPv6 Firewall |
| System Settings | Time Settings |
| | LED Control |
| | Diagnostics |
| | Firmware Upgrade |
| | Backup&Restore |
| | Reboot |
| | Administration |
| | System Log |
| | CWMP Settings |
| Device Management | MERCUSYS APP |
| | Web GUI |
| System Language | English |
| | Spanish |
| | Italian |
| | Polish |
| | Russian |
| TR-069 | ? |
| Hardware |
| Dimensions (W X D X H) | 230.9 × 97.2 × 54.7 mm |
| | (9.1 × 3.8 × 2.2 in) |
| Interfaces | MB118-4G: |
| | 1× 10/100 Mbps LAN (PoE in) |
| | 1× Nano SIM Card Slot |
| | 1× DC Port |
| | PoE Injector: |
| | 1× PoE Out Port |
| | 1× LAN Port |
| | 1× DC Port |
| Antenna | 2× External Detachable LTE Antennas + |
| | 2× Internal Wi-Fi Antennas |
| Button | Reset Button |
| External Power Supply | 12V/1A |
| | support 12V passive PoE, |
| | support 802.3af / 802.3at PoE |
| LED | 1× POWER |
| | 1× Internet |
| | 1× Wi-Fi |
| | 1× LAN |
| | 3× Signal |
| LTE Standard | Cat 4 |
| | 150/50Mbps DL/UL |
| Others |
| Package Contents | 300 Mbps Wireless 4G LTE Outdoor/Indoor Router (MB118-4G) |
| | 2× Antennas |
| | 1× 1.2 m RJ45 Ethernet Cable |
| | 1× PoE Injector |
| | 1× DC Power Adapter |
| | Quick Installation Guide |
| | Window/Pole/Wall Mounting Kits |
| Environment | IP65 weatherproof protection |
| | Operating Temperature: -30°C~60°C (-22°F~140°F) |
| | Storage Temperature: -40°C~70°C (-40 °F~158 °F) |
| | Operating Humidity: 10%~90% RH |
| | Storage Humidity: 5%~90% RH |
