FRACTAL DESIGN vodní chladič Celsius S36, 3x120mm, LGA1851, AM5

FRACTAL DESIGN vodní chladič Celsius S36, 3x120mm, LGA1851, AM5
FRACTAL DESIGN vodní chladič Celsius S36, 3x120mm, LGA1851, AM5
FRACTAL DESIGN vodní chladič Celsius S36, 3x120mm, LGA1851, AM5
FRACTAL DESIGN vodní chladič Celsius S36, 3x120mm, LGA1851, AM5
FRACTAL DESIGN vodní chladič Celsius S36, 3x120mm, LGA1851, AM5
FRACTAL DESIGN vodní chladič Celsius S36, 3x120mm, LGA1851, AM5
FRACTAL DESIGN vodní chladič Celsius S36, 3x120mm, LGA1851, AM5
FRACTAL DESIGN vodní chladič Celsius S36, 3x120mm, LGA1851, AM5
FRACTAL DESIGN vodní chladič Celsius S36, 3x120mm, LGA1851, AM5
FRACTAL DESIGN vodní chladič Celsius S36, 3x120mm, LGA1851, AM5
FRACTAL DESIGN vodní chladič Celsius S36, 3x120mm, LGA1851, AM5
FRACTAL DESIGN vodní chladič Celsius S36, 3x120mm, LGA1851, AM5
FRACTAL DESIGN vodní chladič Celsius S36, 3x120mm, LGA1851, AM5
FRACTAL DESIGN vodní chladič Celsius S36, 3x120mm, LGA1851, AM5
FRACTAL DESIGN vodní chladič Celsius S36, 3x120mm, LGA1851, AM5

Typ chladiče:Vodní; Využití chladiče:Na procesory; Velikost ventilátoru:120x120

Vaše cena: 2 526,50 Kč

Košík:

ks
Koupit
Dostupnost: 13,00

Informace o ceně

Vaše cena bez SNC:
2 526,50 Kč
  • SNC:
    1,50 Kč
  • Vaše cena celkem:
    2 526,50 Kč
Kód:
1208154
P/N:
FD-WCU-CELSIUS-S36-BK
Záruka:
5 Rok(ů)
Výrobce:
Fractal Design
Zástupce v EU:
EAN:
7350041084464
Tisk produktové nabídky Porovnat produkt

Podrobnosti

Celsius S36

The Celsius series is all about delivering the best possible cooling with the least possible noise. Compatible with most common Intel/AMD sockets, including LGA1700 and AM5.

  • Smart temperature-controlled mode adjusts fan/pump speeds in real-time
  • PWM mode enables precision manual tuning for any situation
  • Included PWM fans with wide speed adjustment range (500-2000 RPM)
  • Compatible with LGA 1851 and AM5

TECHNICAL SPECIFICATIONS

Coldplate technology Fifth generation
Coldplate material Copper
Additional sound dampening Integrated
Thermal paste Pre-applied, high thermal conductivity
Sockets supported (Intel) 1851, 1700, 1200, 1150, 1151, 1155, 1156, 1366, 2011, 2011-v3, 2066 (via included 2011-v3 kit)
Sockets supported (AMD) AM2, AM2+, AM3, AM3+, AM4, AM5, FM1, FM2, FM2+, TR4 (via included bracket in AMD Threadripper box)
“CPU brackets and screws may vary due to manufacturer revisions.”
Tube length 400 mm
Tube material Sleeved low-permeability rubber tubes
Fittings, block side Durable metal fittings, non-removable
Fittings, radiator side Durable metal fittings, G 1/4" thread
Fan control Integrated dual mode
Warranty 5-year pre-expansion (Post-expansion, only individual components of the Fractal Design Celsius S24 or S36 are covered)
Fan specifications
Fan type Fractal Design Dynamic X2 GP-12 PWM
Rotational speed 500-2,000 RPM
Bearing LLS
PWM control Yes
Acoustical noise (full speed) 32.2 dB (A)
Maximum air flow 148.8 m3/h | 87.6 CFM
Maximum static pressure 2.30 mm H2O
Input voltage 12 V
Maximum input current 0.2 A
MTBF >100,000 hours
Pump specification
Rotational speed 1,950-3,150 RPM
Bearing type Ceramic bearing and shaft
PWM control Yes
Acoustical noise (full speed) 20,0 dB (A)
Maximum pressure, 50°C 1m H2O | 1.45 PSI
Input voltage 12 V
Input current (without fans) 0.15 A
Rated input power (with fans) 9 W
MTTF >50,000 hours
Radiator specification
Dimensions 403 x 123 x 30 mm
Housing material Aluminum
Fin material Aluminum
Port threads G 1/4"
Fan screw threads UNC 6-32
Other
Package contents Celsius S36 system, 3x Dynamic X2 GP-12 PWM fans, Multilingual user manual, Mounting hardware for all listed sockets, Fan and radiator mounting screws
Package Dimensions 472 x 144 x 177

* Compatible using updated LGA 1700 bracket, contact Fractal support to request one if using an older version

Technické parametry

Velikost ventilátoru 120x120
Využití chladiče Na procesory
Typ chladiče Vodní
