| Special features |
- Double conversion topology
- Constantly regulates voltage and frequency
- Up to 97.2% Energy efficient, Energy Star qualified, reduce energy and cooling costs
- Provides more real power (watts) to protect more equipment with a unity power factor
- Internal bypass allows service continuity in case of UPS fault
- Graphical LCD display
- Hot swappable batteries
|
| Topology |
Online/Double-conversion
|
| Form factor |
Rack/tower
|
| Rack size |
4U
|
| Construction type |
Free standing model
|
| Color |
Black
|
| VA rating |
8 kVA
|
| Wattage |
8 kW
|
| Rack mounting kit |
No
|
| Package contents |
- UPS
- (3) cable glands
- (2) IEC-IEC output cables (1,2m)
- USB cable (1,8m)
- Supports for tower mounting
- Safety instructions
- Quickstart guide
|
| Internal bypass |
Yes
|
| Hot swap power |
No
|
| Auto shutdown function |
Yes
|
| Primary frequency - max |
70 Hz
|
| Primary frequency - min |
40 Hz
|
| Input connection |
Hardwired/fixed connection
|
| Input nominal voltage |
230V default (200/208/220/230/240V)
|
| Nominal frequency |
50/60 Hz
|
| Input frequency range |
40-70 Hz
|
| Input power factor |
>.99
|
| Receptacle |
(8) C13, (4) C19, Hardwired
|
| Number of Outputs C13 |
8
|
| Number of Outputs C19 |
4
|
| Number of outputs hardwired |
1
|
| Output waveform |
Sine wave
|
| Voltage |
230V
|
| Output nominal voltage |
230V default (200/208/220/230/240V)
|
| Feed type |
1
|
| Voltage type |
AC
|
| Runtime graph |
|
| Battery management |
- ABM+ (Predictive battery life) & Temperature compensated charging method (user selectable)
- Automatic battery test
- Deep discharge protection
- Automatic recognition of external battery units
|
| Battery replacement |
Hot-swappable internal batteries and extended battery modules (EBMs)
|
| Battery rating |
12 V / 7 Ah
|
| Battery type |
Sealed, lead-acid
|
| Extended battery capability |
Yes
|
| Runtime at half load |
10.6 min
|
| Communication |
- USB port (HID compliant)
- Serial port (RS232)
- Mini terminal block for remote On/Off
- Mini-terminal block for remote power off
- Mini-terminal block for dry contacts outputs (2 contacts)
|
| Expansion slots |
One slot
|
| Ethernet interface |
No
|
| Includes network card |
No
|
| Software compatibility |
Eaton Brlightlayer Software suite
|
| User interface |
Multilingual graphical LCD display
|
| Type of interface |
Other
|
| Potential free switch contact |
Yes
|
| Altitude |
3000 m
|
| BTU Rating |
Online: 728 BTU/hr
|
| Noise level |
<37 dB at 1 meter
|
| Relative humidity |
0-95% non-condensing
|
| Temperature range |
0° to 40°C (32° to 104°F)
|
| Input voltage - max |
276 V
|
| Input voltage - min |
100 V
|
| Output voltage - max |
240 V
|
| Output voltage - min |
200 V
|
| Secondary frequency - max |
60 Hz
|
| Secondary frequency - min |
50 Hz
|
| Battery quantity |
20
|
| Efficiency at max. load |
97.3
|
| Efficiency (eco-mode) |
99.5
|
| Input voltage range |
176-276 V (100-276 V with derating)
|
| Max number of battery packs |
12
|
| Output frequency |
50/60 Hz
|
| Output power factor |
1
|
| Output voltage range |
200/208/220/230/240 V +/- 1%
|
| Phase (input) |
1
|
| Phase (output) |
1
|
| Runtime at full load |
3.5 min
|
Technické parametry
| Výška v Racku |
6U |
| Typ výstupu |
Svorkovnice |
| Použití |
Server |
| Zdánlivý výkon VA |
8000 |
| Topologie |
On-Line |
| Provedení |
Tower/Rack |
| Fáze (Vstup/Výstup) |
1:1 |
| Možnosti |
Volitelně Management karta |
| Typ balení |
Délka (cm) |
Šířka (cm) |
Výška (cm) |
Hmotnost (kg) |
Počet kusů v balení |
| JEDN |
0 |
0 |
0 |
0 |
1 |
|
