| CPU |
Intel Socket LGA1700 for 13th Gen Intel Core™ Processors & 12th Gen Intel Core™, Pentium Gold and Celeron Processors* |
| Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** |
| * Refer to www.asus.com for CPU support list. |
| ** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types. |
| Chipset |
Intel B760 Chipset |
| Memory |
4 x DIMM, Max. 128GB, DDR4 5333(OC)/5066(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory* |
| Dual Channel Memory Architecture |
| Supports Intel Extreme Memory Profile (XMP) |
| OptiMem II |
| * Supported memory types, data rate(Speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list. |
| Graphics |
1 x DisplayPort** |
| 1 x HDMI port*** |
| * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. // Please refer to AMD CPU specifications. |
| ** Supports max. 4K@60Hz as specified in DisplayPort 1.4 |
| *** Supports 4K@60Hz as specified in HDMI 2.1. |
| **** VGA resolution support depends on processors' or graphic cards' resolution. |
| Expansion Slots |
Intel 13th & 12th Gen Processors |
| 1 x PCIe 5.0 x16 slot |
| Intel B760 Chipset |
| 1 x PCIe 3.0 x16 slot (supports x4 mode)* |
| 2 x PCIe 3.0 x1 slots* |
| * PCIe x1(G3)_1 and PCIe x1(G3)_2 slots share bandwidth with PCIe x16(G3). When PCIe x1(G3)_1 or PCIe x1(G3)_2 slot is operating, PCIe x16(G3) will only supports x2 mode. |
| - To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals. |
| Storage |
Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports* |
| Intel 13th & 12th Gen Processors |
| M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) |
| Intel B760 Chipset |
| M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) |
| M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) |
| 4 x SATA 6Gb/s ports |
| * Intel Rapid Storage Technology supports SATA RAID 0/1/5/10. |
| Ethernet |
1 x Intel 2.5Gb Ethernet |
| ASUS LANGuard // TUF LANGuard |
| Wireless & Bluetooth |
Wi-Fi 6E 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) Supports 2.4/5/6GHz frequency band* Bluetooth v5.3** * WiFi 6E 6GHz regulatory may vary between countries. ** The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications. |
| USB |
Rear USB (Total 9 ports) |
| 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) |
| 1 x USB 3.2 Gen 2 port (1 x Type-A) |
| 3 x USB 3.2 Gen 1 port (2 x Type-A, 1 x USB Type-C) |
| 4 x USB 2.0 ports (4 x Type-A) |
| Front USB (Total 6 ports) |
| 1 x USB 3.2 Gen 2 connector (supports USB Type-C) |
| 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports |
| 1 x USB 2.0 header and 1 x USB 2.0 5-1 pin header support 3 additional USB 2.0 ports |
| Audio |
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 - Impedance sense for front and rear headphone outputs - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input - Supports up to 32-Bit/384 kHz playback |
| Audio Features |
| - SupremeFX Shielding Technology |
| - Savitech SV3H712 AMP |
| - Premium audio capacitors |
| - Dedicated audio PCB layers |
| - Audio cover |
| Back Panel I/O Ports |
1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) |
| 1 x USB 3.2 Gen 2 port (1 x Type-A) |
| 3 x USB 3.2 Gen 1 ports (2 x Type-A, 1 x USB Type-C) |
| 4 x USB 2.0 ports (4 x Type-A) |
| 1 x DisplayPort |
| 1 x HDMI port |
| 1 x Wi-Fi Module |
| 1 x Intel 2.5Gb Ethernet port |
| 5 x Audio jacks |
| 1 x BIOS FlashBack™ button |
| Internal I/O Connectors |
Fan and Cooling related |
| 1 x 4-pin CPU Fan header |
| 1 x 4-pin CPU OPT Fan header |
| 1 x 4-pin AIO Pump header |
| 4 x 4-pin Chassis Fan headers |
| Power related |
| 1 x 24-pin Main Power connector |
| 1 x 8-pin +12V Power connector |
| 1 x 4-pin +12V Power connector |
| Storage related |
| 3 x M.2 slots (Key M) |
| 4 x SATA 6Gb/s ports |
| USB |
| 1 x USB 3.2 Gen 2 connector (supports USB Type-C ) |
| 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports |
| 1 x USB 2.0 header and 1 x USB 2.0 5-1 pin header support 3 additional USB 2.0 ports |
| Miscellaneous |
| 3 x Addressable Gen 2 headers |
| 1 x Aura RGB header |
| 1 x Clear CMOS header |
| 1 x Front Panel Audio header (AAFP) |
| 1 x S/PDIF Out header |
| 1 x 20-5 pin System Panel header |
| 1 x Thunderbolt™ (USB4) header |
| Special Features |
Extreme Engine Digi+ |
| - 5K Black Metallic Capacitors |
| ASUS Q-Design |
| - M.2 Q-Latch |
| - PCIe Slot Q-Release |
| - Q-DIMM |
| - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) |
| - Q-Slot |
| ASUS Thermal Solution |
| - VRM heatsink design |
| ASUS EZ DIY |
| - BIOS FlashBack™ button |
| - BIOS FlashBack™ LED |
| - CPU Socket lever protector |
| - ProCool |
| - Pre-mounted I/O shield |
| - SafeSlot |
| - SafeDIMM |
| Aura Sync |
| - Aura RGB header |
| - Addressable Gen 2 headers |
| Software Features |
ROG Exclusive Software |
| - GameFirst VI |
| - ROG CPU-Z |
| - Sonic Studio III + Sonic Studio Virtual Mixer + Sonic Suite Companion |
| - Sonic Radar III |
| - DTS Sound Unbound |
| ASUS Exclusive Software |
| Armoury Crate |
| - AIDA64 Extreme (60 days free trial) |
| - Aura Creator |
| - Aura Sync |
| - Fan Xpert 4 |
| - Power Saving |
| - Two-Way AI Noise Cancellation |
| AI Suite 3 |
| - DIGI+ VRM |
| - PC Cleaner |
| MyAsus |
| Norton 360 for Gamers |
| WinRAR |
| UEFI BIOS |
| ASUS EZ DIY |
| - ASUS CrashFree BIOS 3 |
| - ASUS EZ Flash 3 |
| - ASUS UEFI BIOS EZ Mode |
| FlexKey |
| MemTest86 |
| BIOS |
256 Mb Flash ROM, UEFI AMI BIOS |
| Manageability |
WOL by PME, PXE |
| Accessories |
Cables |
| 2 x SATA 6Gb/s cables |
| Additional Cooling Kit |
| 1 x Thermal pad for M.2 |
| Miscellaneous |
| 1 x ASUS Wi-Fi moving antennas |
| 1 x Cable ties package |
| 1 x M.2 Q-Latch package |
| 1 x ROG key chain |
| 1 x ROG Strix stickers |
| 1 x ROG Strix thank you card |
| 1 x M.2 Rubber Packages |
| Documentation |
| 1 x User guide |
| Operating System |
Windows 11, Windows 10 64-bit |
| Form Factor |
ATX Form Factor |
| 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
