| CPU |
Intel Socket LGA1700 for 13th Gen Intel Core™ Processors & 12th Gen Intel Core™, Pentium Gold and Celeron Processors |
| Supports Intel 10 nm CPU |
| Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** |
| * Refer to www.asus.com for CPU support list. |
| ** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types. |
| Chipset |
Intel B760 |
| Memory |
4 x DIMM, Max. 128GB, DDR4 Non-ECC, Un-buffered Memory* |
| Dual Channel Memory Architecture |
| Supports Intel Extreme Memory Profile (XMP) |
| OptiMem II |
| * Supported memory types, data rate (speed), and number of DRAM modules vary devpending on the CPU and memory configuration, for more information please refer to CPU/Memory Support under the Support tab or visit https://www.asus.com/support/. |
| Graphics |
1 x HDMI port** |
| 1 x DisplayPort port*** |
| * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. |
| ** Support 4K@60Hz as specified in HDMI 2.1. |
| *** Support max. 8K@60Hz as specified in DisplayPort 1.4. |
| Expansion Slots |
Intel 13th & 12th Gen Processors |
| 1 x PCIe 5.0/4.0/3.0 x16 slot |
| Intel B760 Chipset* |
| 1 x PCIe 4.0 x16 slot (supports x4 mode) |
| 1 x PCIe 3.0 x1 slot** |
| ** PCIe X1 shares bandwidth with M.2_2. PCIe X1 will be disable when M.2_2 runs at PCIe x4 mode by manually enabled. |
| Storage |
Total supports 3 x M.2 slots and 4x SATA 6Gb/s ports* |
| Intel 13th & 12th Gen Processors |
| M.2_1 slot (Key M), type 2242/2260/2280/22110 |
| - Intel 13th & 12th Gen processors support PCIe 4.0 x4 mode. |
| Intel B760 Chipset** |
| M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 mode)*** |
| M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) |
| 4 x SATA 6Gb/s ports*** |
| * Intel Rapid Storage Technology supports SATA RAID 0/1/5/10. |
| *** M.2_2 slot shares bandwidth with PCIe X1 and WiFi Key E. M.2_2 will run at PCI 3.0 x2 mode either a device is detected at PCIe x1 or WiFi Key E slot. |
| Ethernet |
1 x Realtek 2.5Gb Ethernet |
| 1 x Intel 1Gb Ethernet |
| ASUS LANGuard |
| Wireless & Bluetooth |
M.2 slot only (Key E, PCIe)* *Wi-Fi module is sold separately. |
| USB |
Rear USB (Total 9 ports) |
| 1 x USB 3.2 Gen 2 Type-C port |
| 4 x USB 3.2 Gen 1 ports (4 x Type-A) |
| 4 x USB 2.0 ports (4 x Type-A) |
| Front USB (Total 7 ports) |
| 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C) |
| 1 x USB 3.2 Gen 1 header supports additional 2 x USB 3.2 Gen1 ports |
| 2 x USB 2.0 headers support additional 4 USB 2.0 ports |
| Audio |
Realtek 7.1 Surround Sound High Definition Audio CODEC* - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback |
| Audio Features |
| - Premium audio capacitors |
| - Dedicated audio PCB layers |
| - Audio cover |
| - Unique de-pop circuit |
| Back Panel I/O Ports |
1 x USB 3.2 Gen 2 port (1 x USB Type-C) |
| 4 x USB 3.2 Gen 1 ports (4 x Type-A) |
| 4 x USB 2.0 ports (4 x Type-A) |
| 1 x DisplayPort |
| 1 x HDMI port |
| 1 x Realtek 2.5Gb Ethernet port |
| 1 x Intel 1Gb Ethernet port |
| 5 x Audio jacks |
| 1 x Optical S/PDIF out port |
| Internal I/O Connectors |
Fan and Cooling related |
| 1 x 4-pin CPU Fan header |
| 1 x 4-pin CPU OPT Fan header |
| 1 x 4-pin AIO Pump header |
| 4 x 4-pin Chassis Fan headers |
| Power related |
| 1 x 24-pin Main Power connector |
| 1 x 8-pin +12V Power connector |
| 1 x 4-pin +12V Power connector |
| Storage related |
| 3 x M.2 slots (Key M) |
| 4 x SATA 6Gb/s ports |
| USB |
| 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C) |
| 1 x USB 3.2 Gen 1 header supports additional 2 x USB 3.2 Gen1 ports |
| 2 x USB 2.0 headers support additional 4 USB 2.0 ports |
| Miscellaneous |
| 3 x Addressable Gen 2 headers |
| 1 x AURA RGB header |
| 1 x Clear CMOS header |
| 1 x COM Port header |
| 1 x Front Panel Audio header (AAFP) |
| 1 x M.2 slot (Key E) |
| 1 x SPI TPM header (14-1pin) |
| 1 x 20-5 pin System Panel header |
| 1 x Thermal Sensor header |
| 1 x Thunderbolt™ header |
| Special Features |
ASUS 5X PROTECTION III |
| - DIGI+ VRM (- Digital power design with DrMOS) |
| - Enhanced DRAM Overcurrent Protection |
| - ESD Guards |
| - LANGuard |
| - Overvoltage Protection |
| - SafeSlot |
| - Stainless-Steel Back I/O |
| ASUS Q-Design |
| - M.2 Q-Latch |
| - Q-Connector |
| - Q-DIMM |
| - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) |
| - Q-Slot |
| ASUS Thermal Solution |
| - Flexible M.2 heatsink |
| - VRM heatsink design |
| ASUS EZ DIY |
| - ProCool |
| - Pre-mounted I/O shield |
| AURA Sync |
| - AURA RGB header |
| - Addressable Gen 2 headers |
| Software Features |
ASUS Exclusive Software |
| Armoury Crate |
| - AURA Creator |
| - AURA Sync |
| - Fan Xpert 4 |
| - Power Saving |
| - Two-Way AI Noise Cancelation |
| AI Suite 3 |
| - Performance And Power Saving Utility |
| DIGI+ VRM |
| Turbo app |
| ASUS CPU-Z |
| IT Management software supported |
| - ASUS Control Center Express(ACCE) |
| ProArt Creator Hub |
| CreationFirst |
| Norton 360 Deluxe (60 Days Free Trial) |
| WinRAR |
| UEFI BIOS |
| ASUS EZ DIY |
| - ASUS CrashFree BIOS 3 |
| - ASUS EZ Flash 3 |
| - ASUS UEFI BIOS EZ Mode |
| BIOS |
128 Mb |
| Manageability |
WOL by PME, PXE |
| Accessories |
Cables |
| 2 x SATA 6Gb/s cables |
| Miscellaneous |
| 2 x M.2 Rubber packages |
| 1 x Screw package for M.2 Key E |
| 1 x ProArt ruler |
| 1 x Q-connector |
| Documentation |
| 1 x ACC Express Activation Key Card |
| 1 x User guide |
| Operating System |
Windows 11 64-bit, Windows 10 64-bit |
| Form Factor |
ATX Form Factor |
| 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
